Carrier QHG012DS
Model QHG012DS
3.5 kW (12,000 BTU/h)
EER 3.24 W/W
R410A
Inverter
Carrier QHG inverter midwall splits deliver efficient, quiet cooling and heating in a compact hi-wall design. Using R410A refrigerant and inverter compressor technology, they provide reliable comfort with reduced energy consumption in residential or light-commercial spaces.
Full specifications
| Performance | |
|---|---|
| Cooling Capacity | 3.5 kW |
| Cooling Capacity (BTU) | 12,000 BTU/h |
| Heating Capacity | 3.8 kW |
| EER | 3.24 W/W |
| COP | 3.45 W/W |
| Energy Rating | Cooling A / Heating A+ |
| COP / EER | 3.45 W/W |
| Electrical | |
| Power Supply | 220-240V / 1 Ph |
| Power Input Kw | 1.08 |
| Rated Current A | 4.8 |
| Refrigerant | |
| Refrigerant Type | R410A |
| Pipe Size – Liquid | 6.35 mm |
| Pipe Size – Gas | 9.52 mm |
| Max Pipe Length M | 25 |
| Physical – Indoor | |
| Dimensions Indoor Mm | 806x200x296 |
| Weight Indoor Kg | 9.0 |
| Noise Indoor Db | 40.0 |
| Features | |
| Inverter | Yes |
